Vapor recovery stages are usually described by mechanism, but the practical question is which mechanism suits a particular stream. Condensation, absorption, adsorption and membranes each respond to a different property of the vapor: temperature, solubility, surface affinity and partial pressure. Once the stream is characterised by concentration, composition, moisture and flow, the choice of stage usually narrows quickly, and the remaining decision is how many stages to combine.
What each mechanism responds to
Condensation responds to temperature and dew point. Absorption responds to solubility in a contacting liquid. Adsorption responds to the affinity between the vapor and a solid surface. Membrane separation responds to partial pressure and the relative permeability of the components. Each has a range of concentration where it works well and a range where it becomes expensive.
Where each stage fits best
| Stage | Responds to | Suits streams that are |
|---|---|---|
| Condensation | Temperature and dew point | High concentration and readily condensable |
| Absorption | Solubility in a liquid | Moderate concentration with a suitable solvent |
| Adsorption | Surface affinity | Low concentration with a need for a very low outlet |
| Membrane | Partial pressure and permeability | Low to moderate concentration needing enrichment |
| Combination | More than one property | Wide concentration range or strict outlet limits |
Reading the stream before choosing the stage
Four stream characteristics carry most of the decision. Concentration sets which mechanisms are economically sensible. Composition decides whether the components will condense, dissolve or adsorb. Moisture affects adsorption capacity and membrane performance and raises frost risk in condensation. Flow rate and its variability decide whether the stage can be designed around a steady operating point or has to handle a wide range.
Outlet requirement matters as much as the inlet stream. A stage that removes most of the hydrocarbon cheaply may still not reach a low outlet limit, in which case a second stage is added specifically to close the gap rather than to carry the bulk load.
A structured way to choose
- Measure or estimate inlet concentration and its variability;
- Establish the composition, including moisture and heavy components;
- Set the required outlet concentration from the site’s obligation;
- Identify which mechanism suits the concentration range of the stream;
- Check whether one stage reaches the outlet requirement or a second is needed;
- Confirm the combination remains stable across the expected turndown.
Frequently asked questions
Is one stage usually enough?
For moderate concentration and a modest outlet requirement, one stage often is. Where the concentration range is wide or the outlet limit is low, a combination removes the bulk with one mechanism and closes the gap with another.
Does the cheapest stage always give the lowest cost of ownership?
Not necessarily. A stage that is cheap to buy but needs frequent media replacement or regeneration can cost more over its life than a more capable first stage. Both the capital and the operating side should be considered together.
How much does moisture matter?
It affects several stages in different ways, so it is worth measuring rather than assuming. In condensation it raises frost risk, in adsorption it competes for capacity, and in membrane separation it can affect performance and life.
