Expectations around tank farm vapor emissions have shifted from the equipment itself towards the evidence that the equipment is working. Operators are increasingly asked to show not only that a vapor recovery unit was installed but that it operates within its intended range over time. That change benefits from being anticipated, because the record set is much easier to establish while a unit is new than to reconstruct several years into its life.
Why the emphasis moved to records
A vapor recovery unit’s performance depends on conditions and maintenance, not only on its specification. Two identical units can behave differently because of how they are operated and how often their heat transfer surfaces are cleaned. Records are the practical way to show which of those situations applies, and they also give the operator the information needed to intervene before performance degrades.
What is worth recording routinely
| Record | Frequency | Why it is useful |
|---|---|---|
| Inlet and outlet temperature | Each operating period | Shows condenser duty and drift |
| Pressure drop across the train | Each operating period | Indicates loading and fouling |
| Throughput during operation | Each operating period | Allows performance to be normalised |
| Ambient temperature | Daily | Separates seasonal effects from deterioration |
| Maintenance actions and dates | As they occur | Links performance change to intervention |
| Recovered liquid quantity | As measured | Confirms the unit is recovering material |
Making the record set sustainable
Records fail for a predictable reason: they ask for more than the site can sustain. A short list that is completed consistently produces a more useful evidence base than a comprehensive form that is filled in sporadically. Where automatic logging is available, it removes most of the effort, but the manual observations that machines cannot make, such as unusual noise or visible leakage, still need a place in the routine.
Getting the routine established
- Decide the shortest record set that answers the questions likely to be asked;
- Define who records what, and at what frequency;
- Record normal results as well as exceptions, so trends are visible;
- Keep ambient temperature alongside unit readings to separate seasonal effects;
- Link maintenance actions to the performance record so changes can be explained;
- Review the record periodically and adjust the list as understanding improves.
Frequently asked questions
Is a record set needed for small sites as well?
The same principle applies, although the list can be shorter. What matters is that the records show the unit has been operated and maintained, which is the question most likely to arise.
How long should records be kept?
Long enough to show performance over time, which in practice means several years. Retaining records is much easier if the format does not change frequently.
Do automatic systems remove the need for manual records?
They remove the routine readings, but not the observations that require a person on site, and not the record of maintenance actions. A combined routine is what produces a usable evidence base.
